Low Cost Single Axis Tilt Sensor Digital Output

Low Cost Single Axis Tilt Sensor Digital Output

ER-TS-5146DI Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.3°, resolution 0.05°;
3. Output frequency 5~100HZ (optional).

Low Cost Single Axis Tilt Sensor Digital Output

Low Cost Single Axis Tilt Sensor Digital Output

Get Price Now



    Share to:

    Introduction

    Low Cost Single Axis Tilt Sensor Digital Output

    Introduction
    ER-TS-5146DI Digital Single Axis Tilt Meter is a new generation of digital small-volume MEMS tilt sensor with a built-in dual-channel gravity tilt unit converts the tilt change by measuring the static gravitational acceleration. Thus the sensor output can be measured with respect to the horizontal plane tilt and pitch angle. The output mode has RS232, RS485 or TTL, MODBUS level interface to choose from. Due to the built-in MCU control system, the output linearity of the sensor has been corrected twice to make up for the loss of accuracy caused by the lack of analog correction.
    The product adopts non-contact measurement of the original quantity, which can output the current attitude and inclination in real time. The operation is simple, and there is no need to retrieve the two sides of the change. It can resist external electromagnetic interference and adapt to harsh industrial environment for long-term work, so it is an ideal choice for industrial automation control and platform attitude measurement.

    Features
    Single axis tilt monitoring
    Full range accuracy 0.3°, resolution 0.05°
    Output frequency 5~100HZ (optional)
    Input voltage DC 5V, (9-36 can be customized)
    Wide temperature working -40~+85℃
    Measuring range: 0~±180° (optional)
    High vibration resistance>2500 g
    Baud rate 2400~115200 (adjustable)
    IP67 Protection
    Output: RS232/RS485/TTL/MODBUS (optional)
    Small volume (55*37*24mm) (customizable)

    Applications
    High voltage power line tower pole monitoring
    Satellite solar antenna positioning
    Aerial work vehicle
    Mining machinery, oil logging equipment
    Medical equipment
    Tripod head levelling
    Hydraulic lifting platform
    Tilt based monitoring
    Various construction machinery angle control
    Inspection of bridges and dams

    Specifications

    Parameters Conditions ER-TS-5146DI-10 ER-TS-5146DII-30 ER-TS-5146DI-60 ER-TS-5146DI-90 Unit
    Measuring range / ±10 ±30 ±60 ±90 °
    Measuring axis / X X X X /
    Zero temperature drift -40~85° ±0.05 ±0.05 ±0.05 ±0.05 °/℃
    Sensitivity  temperature coefficient -40~85° ≤200 ≤200 ≤200 ≤200 ppm/℃
    Frequency response DC response 100 100 100 100 Hz
    Resolution Bandwidth 5Hz 0.05 0.05 0.05 0.05 °
    Accuracy -40~85℃ 0.3 0.3 0.3 0.3 °
    Long term stability -40~85℃ <0.32 °
    Power on time / 0.2 0.2 0.2 0.2 s
    Response time / 0.01 0.01 0.01 0.01 s
    Rate 5Hz output, 15Hz, 35Hz, 50Hz, 100Hz can be set (RS485 does not have this function)
    Output signal RS232/RS485/RS422/TTL/PWM/CAN/MODBUS
    Average failure-free work ≥55000 hours/time
    Shock resistance 2500g, 0.5ms, 3 times/axis
    Anti-vibration 10grms, 10~1000Hz
    Insulation Resistance ≥100MΩ
    Waterproof level IP67
    Cables Standard 1.5M length, wearproof, grease proofing, wide temperature, shielded cables4*0.2mm²
    Weight 75g (without packing box)
