Ericco's tilt sensor 0.005 offers precise service for your downhole exploitation. We can assure the high quality and high security of our tilt sensor 0.005. Various sizes and special functions are also available. Just come and get more details with us.
ER-TS-2180VO Features:
1. Single axis tilt monitoring;
2. Output 0~5V, 0.5~4.5V, 0~10V (optional);
3. Full range accuracy 0.005°, resolution 0.0007°.
ER-TS-2185CA Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.005°, resolution 0.0007°;
3. Output frequency 5~100HZ (optional).
ER-TS-2186DI Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.005°, resolution 0.0007°;
3. Output frequency 5~100HZ (optional).
ER-TS-2188CU Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.005°, resolution 0.0007°;
3. Output interface 4~20mA, 0~20mA, 0~24mA (optional).
ER-TS-3160VO Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.01°, resolution 0.001°;
3. Output 0~5V, 0.5~4.5V, 0~10V (optional).
ER-TS-3165CA Features:
1. Single axis tilt monitoring;
2. Output frequency 5~100HZ (optional);
3. Full range accuracy 0.01°, resolution 0.001°.
ER-TS-3166DI Features:
1. Single axis tilt monitoring;
2. Output frequency 5~100HZ (optional);
3. Full range accuracy 0.01°, resolution 0.001°.
ER-TS-3168CU Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.01°, resolution 0.001°;
3. Output 4~20mA, 0~20mA, 0~24mA (optional).
ER-TS-4150VO Features:
1. Single axis tilt monitoring;
2. Output: 0-5V, 0.5~4.5V, 0-10V (optional);
3. Full range accuracy 0.1°, resolution 0.01°.
ER-TS-4155CA Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.1°, resolution 0.01°;
3. Wide voltage input DC 9～36V.
ER-TS-4156DI Features:
1. Single axis tilt monitoring;
2. Wide voltage input DC 9~36V;
3. Full range accuracy 0.1°, resolution 0.01°.
ER-TS-4158CU Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.1°, resolution 0.01°;
3. Output 4~20mA, 0~20mA, 0~24mA optional.
ER-TS-5140VO Features:
1. Single axis tilt monitoring;
2. Output: 0-5V, 0.5~4.5V, 0-10V (optional);
3. Full range accuracy 0.3°, resolution 0.05°.
ER-TS-5145CA Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.3°, resolution 0.05°;
3. Output frequency 5~100HZ (optional).
ER-TS-5146DI Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.3°, resolution 0.05°;
3. Output frequency 5~100HZ (optional).
ER-TS-5148CU Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.3°, resolution 0.05°;
3. Output 4~20mA, 0~20mA, 0~24mA optional.
