ER-TS-5148CU Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.3°, resolution 0.05°;
3. Output 4~20mA, 0~20mA, 0~24mA optional.

Current Output Type Single Axis tilt Sensor

Current Output Type Single Axis tilt Sensor

Get Price Now



    Share to:

    Introduction

    Product Description
    ER-TS-5148CU Current Single Axis Tilt Meter is a small volume MEMS single-axis current output tilt meter, the output current of 4~20mA, 0~20mA, 0~24mA is optional. Due to the built-in micro-electromechanical production process inclination device, the product is small in size, low in power consumption, industrial-grade working temperature is -40~+85℃, and long-distance transmission can reach more than 2500 meters. The strong ability to resist external electromagnetic interference makes it suitable for long-term work in harsh industrial environments.
    The product adopts the principle of non-contact measurement, which can output the current attitude and inclination angle in real time with an accuracy up to 0.3°. It is simple to use, and there is no need to find the two surfaces with relative changes, so it is the ideal choice of industrial equipment and platform attitude measurement.

    Features
    Single axis tilt monitoring
    Full range accuracy 0.3°,  resolution 0.05°
    Output 4~20mA, 0~20mA, 0~24mA optional
    Wide voltage input DC 9~36V
    Wide temperature working -40~+85℃
    Measuring range: 0~±180° (optional)
    High vibration resistance>2500 g
    IP67 Protection
    Industrial design
    Small volume (55*37*24mm) (customizable)

    Applications
    Intelligent power transmission line
    High altitude working vehicle
    Tractor, deep farming machinery
    Mining machinery, oil logging equipment
    Medical equipment
    Tripod head levelling
    Hydraulic lifting platform
    Inclination monitoring
    Angle control of various construction machinery
    Inspection of bridges and dams

    Specifications

    Parameters Conditions ER-TS-5148CU-10 ER-TS-5148CU-30 ER-TS-5148CU-60 ER-TS-5148CU-90 Unit
    Measuring range / ±10 ±30 ±60 ±90 °
    Measuring axis Y-axis is optional X X X X /
    Zero temperature drift -40~85° ±0.05 ±0.05 ±0.05 ±0.05 °/℃
    Sensitivity temperature coefficient -40~85° ≤200 ≤200 ≤200 ≤200 ppm/℃
    Zero drift 0° output 0~40mA output 12mA, 0~20 mA output 10mA, 0~24 mA output 12mA mA
    Frequency response DC response 100 100 100 100 Hz
    Resolution Bandwidth 5Hz 0.05 0.05 0.05 0.05 °
    Accuracy -40~85℃ 0.3 0.3 0.3 0.3 °
    Long term stability -40~85℃ <0.32 °
    Power on time / 0.2 0.2 0.2 0.2 s
    Response time / 0.01 0.01 0.01 0.01 s
    Average failure-free work ≥55000hours/time
    Output signal 4-20mA, 0~20mA, 0~24mA
    Shock resistance 2500g, 0.5ms, 3 times/axis
    Anti-vibration 10grms, 10~1000Hz
    Insulation Resistance ≥100MΩ
    Waterproof level IP67
    Cables Standard 1.5M length, wearproof, grease proofing, wide temperature, shielded cables4*0.3mm²
    Weight 55g (without packing box)
