Low-Cost CANopen Output Type Tilt Sensor

Low-Cost CANopen Output Type Tilt Sensor

ER-TS-5275CA Features:
1. Two axis tilt monitoring;
2. Stable accuracy of 0.05°;
3. Dynamic measurement accuracy of 0.3°.

Low-Cost CANopen Output Type Tilt Sensor

Low-Cost CANopen Output Type Tilt Sensor

Get Price Now



    Share to:

    Introduction

    Low-Cost CANopen Output Type Tilt Sensor

    Introduction
    ER-TS-5275CA CAN output two-axis tilt meter is a new generation of high-performance, small-sized, high-precision inclination sensor that can be maintained in complex movements. The dynamic measurement accuracy is 0.3°, the stability accuracy is 0.05°, and the temperature drift is 0.01°/℃. The output mode is CAN bus, which is easy to integrate into the user control system.
    The product has a built-in MCU control system, vertical gyroscope and accelerometer, adopts the optimal digital filter algorithm to reduce noise, and cooperates with the N-order Kalman filter algorithm. Through nonlinear compensation, quadrature compensation, temperature drift and other compensation, error sources can be eliminated and improved measurement accuracy. It can accurately output objects in strong vibration and motion environment posture angle.

    Features
    Two axis tilt monitoring
    Dynamic measurement accuracy of 0.3°
    Stable accuracy of 0.05°,
    Vertical gyroscope/N-order Kalman filter
    Input voltage DC 5V (9~36 customizable)
    Wide temperature working -40~+85℃
    Range 0~±90°(optional)
    High nonlinear compensation
    Orthogonal compensation
    Temperature compensation
    Baud rate 100~500K bps (adjustable)
    Protection level IP67
    Output CANopen
    Small volume (55*37*24mm) (customizable)

    Applications
    Balance car
    Agricultural machinery, rotary drilling rig
    AGV car
    Mining machinery, oil logging equipment
    Medical equipment
    Hydraulic lifting platform
    Inclination monitoring
    Angle control of various construction machinery
    Bridges and DAMS, monitoring

    Specifications

    Parameter Condition ER-TS-5275CA-10 ER-TS-5275CA-30 ER-TS-5275CA-60 ER-TS-5275CA-90 Unit
    Measuring range / ±10 ±30 ±60 ±90 °
    Measurement of shaft / X, Y Axis X, Y Axis X, Y Axis X, Y Axis /
    Zero temperature drift -40~85° ±0.01 ±0.01 ±0.008 ±0.01 °/℃
    Sensitivity temperature coefficient -40~85° ≤150 ≤150 ≤150 ≤150 ppm/℃
    Frequency response DC response 100 100 100 100 Hz
    Resolution / 0.01 0.01 0.01 0.01 °
    Accuracy -40~85℃ 0.3 0.3 0.3 0.3 °
    Long-term stability -40~85℃ <0.35 °
    Power on start time / 0.2 0.2 0.2 0.2 s
    Response time / 0.01 0.01 0.01 0.01 s
    Rate 5Hz output, 15Hz, 35Hz, 50Hz and 100HZ can set (RS485 without this function)
    Output signal CANopen
    Average working time ≥55,000 hours/time
    Impact resistant 25000g, 0.5ms, 3 times/axis
    Shock resistant 10grms, 10~1000Hz
    Insulation resistance ≥100MΩ
    Waterproof level IP67
    Cable Standard 1.5 m length, wear resistance, oil proof, wide temperature, shielding cable 4*0.2mm²
    Weight 75g (excluding boxes)
