Digital Output 2 Axis Tilt Sensor

Digital Output 2 Axis Tilt Sensor

ER-TS-5246DI Features:
1. Two axis tilt monitoring;
2. Output frequency 5~100HZ optional;
3. Full range accuracy 0.3°, resolution 0.05°.

Digital Output 2 Axis Tilt Sensor

Digital Output 2 Axis Tilt Sensor

Get Price Now



    Share to:

    Introduction

    Digital Output 2 Axis Tilt Sensor

    Introduction
    ER-TS-5246DI Digital Two Axis Tilt Meter is a new generation of digital small volume MEMS tilt sensor with built-in dual channel earth gravity tilt unit, which can be converted into inclination change by measuring static gravity acceleration. Thus, the tilt and pitch angle of the sensor output relative to the horizontal plane can be measured. The output mode has RS232, RS485 or TTL and MODBUS can choose. Due to the built-in MCU control system, the output linearity can be modified twice, which makes up for the accuracy drop caused by insufficient correction in the simulation model.
    The product adopts non-contact measurement original quantity, which can output the current attitude inclination in real time. It is simple to use, and there is no need to retrieve the two surfaces of phase change installation. It is an ideal choice for industrial automatic control and platform attitude measurement with strong resistance to external electromagnetic interference and can be adapted to work in harsh industrial environment for a long time.

    Features
    Two axis tilt monitoring
    Full range accuracy 0.3°, resolution 0.05°
    Output frequency 5~100HZ optional
    Input voltage DC 5V
    Wide temperature working -40~+85℃
    Range 0~±90° (optional)
    High vibration resistance>2500g
    Baud rate 2400~115200 (adjustable)
    IP67 protection level
    Output RS232/RS485/TTL/MODBUS (optional)
    Small volume (55*37*24mm) (customizable)

    Applications
    High voltage power line tower pole monitoring
    Satellite solar antenna positioning
    Aerial work vehicle
    Mining machinery, oil logging equipment
    Medical equipment
    Hydraulic lifting platform
    Tilt based monitoring
    Various construction machinery angle control
    Inspection of bridges and dams

    Specifications

    Parameter Condition ER-TS-5246DI-10 ER-TS-5246DI-30 ER-TS-5246DI-60 ER-TS-5246DI-90 Unit
    Measuring range / ±10 ±30 ±60 ±90 °
    Measurement of shaft / X, Y Axis X, Y Axis X, Y Axis X, Y Axis /
    Zero temperature drift -40~85° ±0.05 ±0.05 ±0.05 ±0.05 °/℃
    Sensitivity temperature coefficient -40~85° ≤200 ≤200 ≤200 ≤200 ppm/℃
    Frequency response DC response 100 100 100 100 Hz
    Resolution Bandwidth 5Hz 0.05 0.05 0.05 0.05 °
    Accuracy -40~85℃ 0.1 0.1 0.1 0.1 °
    Long-term stability -40~85℃ <0.33 °
    Power on start time / 0.2 0.2 0.2 0.2 s
    Response time / 0.01 0.01 0.01 0.01 s
    Rate 5Hz output, 15Hz, 35Hz, 50Hz and 100HZ can set (RS485 without this function)
    Output signal RS232 / RS485 / RS422 / TTL/PWM/CAN/MODBUS
    Average working time ≥55,000 hours/time
    Impact resistant 2500g, 0.5ms, 3 times/axis
    Shock resistant 10grms, 10~1000Hz
    Insulation resistance ≥100MΩ
    Waterproof level IP67
    Cable Standard 1.5 m length, wear resistance, oil proof, wide temperature, shielding cable 4*0.2mm²
    Weight 75g (excluding boxes)
