High Accuracy 3-Axis MEMS Gyro
ER-3MG-09
1. Cylinder;
2. Bias Instability (1σ 25℃): 0.01-0.02º/h;
3. Size: 120mm x Φ30mm.
High Performance 3-Axis MEMS Gyro
ER-3MG-10
1. Cylinder;
2. Bias Instability (1σ 25℃): 0.03-0.05º/h;
3. Size: 120mm x Φ30mm.
Integrated Dual Processor Core CPU
ER-CPU-22K
1. Integrated 72-bit DDR4 Controller (including 8-bit ECC);
2. Integrated two SATA3.0 interfaces;
3. Adopt FC-BGA encapsulation.
Strong Driving Force CPU
ER-CPU-35A/35B
1. Based on New Arch™;
2. High bandwidth memory interface: Support DDR4-3200, the actual bandwidth is more than 25GB/s;
3. Integrated Eco-compatibility: Real-time translation for applications with different architectures.
High Efficiency Cloud CPU
ER-CPU-35C
1. New instruction system;
2. High-end multiplexing;
3. High system performance.
Low Power Consumption Wireless Transmission Tilt Sensor
ER-TS-22800 Feature:
1. Accuracy: 0.005°, resolution: 0.0008°;
2. Measurement range: ± 30°;
3. Volume (94*74*64mm) (customizable).
Economical CPU
ER-CPU-71A
1. Graphics card memory: 16-bit DDR3 controller;
2. Supports dual-channel DVO display;
3. Power Consumption5-8W.
High Performance Wireless Transmission Tilt Sensor
ER-TS-32600-Modbus Features:
1. Dual axis monitoring (single axis optional);
2. Full range accuracy 0.01°, resolution 0.002°;
3. Volume (94*74*64mm) (customizable).
High Precision Stable-control MEMS Gyro
ER-3MG-11
1. Cylinder;
2. Bias Instability (1σ 25℃): 0.3-0.1º/h;
3. Light Weight.
Low Cost 3-Axis MEMS Gyro
ER-3MG-12
1. Cylinder;
2. Bias Instability (1σ 25℃): 1º/h;
3. Light Weight.
Independent Display Bridge CPU
ER-CPU-72A
1. Supports up to 16GB video memory capacity;
2. PCIE, USB, and SATA are all upgraded to 3.0;
3. One GMAC network port +1RGMII port.
3-Axis North-Seeking MEMS Gyro
ER-3MG-14
1. Thin;
2. Light weight;
3. Simple structure and good reliability.
High Accuracy Liquid Floating Rate Gyroscope
ER-RG-6 (≤0.008°/s)
1. Zero stability≤0.008°/s;
2. Suitable for servo stabilization system;
3. High performance liquid floating rate gyro.
High Performance Navigation MEMS Gyro
ER-3MG-15
1. Thin;
2. Light weight;
3. Simple structure and good reliability.
Economical FOG Gyroscope
ER-FOG-70 (0.05~0.1º/h)
1. Bias stability: 0.05~0.1º/h;
2. Small size;
3. Light weight.
High Accuracy FOG Gyroscope
ER-FOG-98 (0.008-0.08º/h)
1. Bias stability: 0.008-0.08º/h;
2. Dimension: Φ98mm×38mm.
Low Cost 2D Electronic Compass
ER-EC-225:
1. Heading accuracy 1°, tilt range ±5°;
2. Measurement range 0~360°;
3. With hard magnetic, soft magnetic and tilt compensation.
High Precision 2D Electronic Compass
ER-EC-225CAN:
1. Measurement range 0~360°;
2. Heading accuracy 1°, tilt range ±5°;
3. Industrial grade design.
Small Size High Precision Direction Finding Board
ER-GNSS-B06
1. Onboard IMU, provide tilt, roll and other attitude information;
2. Direction finding accuracy is better than 0.08°(@1.0m antenna distance);
3. Full support for BEidou-3 satellite signal reception, full-frequency point direction finding of the whole constellation.
Gyro While Drilling FOG INS
ER-Gyro-03 (0°~180°/±0.2°)
1. Inclination: ±0.2°; azimuth: ±2.0°; tool face angle: ±0.5°;
2. Measure while drilling & real-time upload & draw of measurement data;
3. Automatic north seeking & continuous attitude and position measurement.
Small Diameter Measurement While Drilling
ER-MWD-38 (Φ38mm)
1. Azimuth: 0~360°/±1°;
2. Inclination: 0~180°/±0.1°;
3. Tool face angle: 0~360°/±2.
Low Cost Measurement While Drilling
ER-MWD-48 (0~180°/±0.1° MWD-Φ48mm)
1. Azimuth: 0~360°/±1°;
2. Inclination: 0~180°/±0.1°;
3. Tool face angle: 0~360°/±0.5.
Small Size DTG Gyroscope
ER-DTG-E1:
1. Random drift: 0.3-0.8°/h;
2. Very small size: Φ21.4×30mm;
3. Strong shock resistance.
