In a rapidly changing tactical environment, millisecond errors can be the difference between success and failure. Ericco has released a new product, the ER-FIMU-40 FOG IMU, tailored for demanding tactical systems, with military-grade reliability, extreme accuracy and rapid response, becoming the ultimate solution for navigation and control in highly dynamic scenarios!
**Why ER-FIMU-40?**
✅ Military-grade reliability: all-solid three-axis fiber optic gyroscope (FOG) and three-axis quartz flexible accelerometer, no moving parts design, shock resistance, vibration resistance, stable operation under extreme temperatures of -50℃ to +80℃, adapt to the harsh challenges of battlefield and deep space environment.
✅ Nanoscale accuracy:
Gyroscope: Bias stability ≤0.035º/h (100s), random walk coefficient as low as 0.01º/√h, dynamic environment still maintains submicro radian level accuracy.
Accelerometer: resolution 5μg, nonlinear error ≤±30μg/g², weak vibration and high-speed maneuvering can be accurately captured.
✅ Fast response, control the overall situation:
Gyro bandwidth ≥500Hz, accelerometer bandwidth up to 2500Hz, 200Hz real-time data output, dynamic delay is close to zero, for flight control, imaging stability and other scenarios to provide instantaneous decision support.
✅ Compact and lightweight: only 100×100×75mm in size and 1.06kg in weight, easily integrated into UAS, airborne equipment or portable tactical equipment to unlock space potential.
**Application scenario**: Precise and unbounded, enabling cutting-edge fields
Defense and Aerospace: Flight control systems, airborne weapon stabilization platforms
Unmanned system: Unmanned aerial vehicle (UAV) autonomous navigation, cluster collaborative positioning
High precision mapping: Lidar motion compensation, terrain mapping attitude reference
Industrial strength: robot dynamic balance, heavy machinery motion control
Research test: inertial navigation algorithm verification, high dynamic simulator calibration
**Technical specification highlights**
| Core performance | parameter |
| Gyroscope | range±500º/s, bandwidth≥500Hz |
| Accelerometer | range±50g, noise≤8.4mV |
| Data output | 200Hz high speed synchronization, RS-422interface (support for customization) |
| Environmental adaptability | -50℃ to +80℃ wide temperature operation, all solid shock resistance |
**Born for tactics, fought to win**
ER-FIMU-40 is not only a sensor, it is the cornerstone of mission success! Whether it is a high-altitude high-speed aircraft, or unmanned reconnaissance equipment deep behind enemy lines, it always escorts every second decision in a complex environment with military-grade stability and laborator-grade accuracy.
**Act now to open a new era of precision!**
Consult: Get customized solutions and sample testing
Technical Line: Contact an engineer to unlock your dedicated tactical IMU configuration
