High-precision IMU assists precise operation in oil and mining industries

In the oil and mining industries, technological innovation is the key to driving development. IMU, as a core sensor technology, can measure the angular velocity and acceleration of an object in real-time, providing critical data support. Therefore, we have specially developed the ER-MIMU-09 for the oil and mining industries, aiming to help well logging and mining operations achieve higher precision and efficiency.

High Precision #imu Assists Precise Operation In #oil And #mining Industries

Optimized design for maximum space utilization

The ER-MIMU-09 adopts an irregular cylindrical design with a volume of 120mm x φ30mm and a weight of no more than 150g. This design not only makes installation easier, but also maximizes performance in limited space, meeting the application requirements of the complex environments in the oil and mining industries.

High performance for precise measurement assurance

The IMU is equipped with a triaxial high-precision gyroscope and a triaxial high-precision accelerometer. The bias instability of the gyroscope is as low as 0.01º/h,and the angular random walk is less than 0.0025 °/√h; the bias repeatability of the accelerometer is 100ug (high-temperature version 30ug), the bias stability (10s 1σ) is less than 50ug (high-temperature version <5ug), providing solid assurance for high-quality well logging.

Low power consumption for long-lasting operation

The IMU adopts a low-power design, coupled with an efficient power management system, ensuring stable operation within a wide voltage range of 6~12V, with a power consumption of only 2W, maximizing battery life.

Temperature compensation for harsh environments

With temperature compensation ranges of -40°C to 80°C (high-temperature version -40°C to +125°C), the IMU is able to adapt to various harsh environments and ensure high-performance operation in well logging and mining complex environments.

Efficient communication for enhanced operation efficiency

This IMU also supports RS422 bus communication, with baud rates ranging from 230400 to 921600 adjustable, allowing for fast and stable data exchange with various devices and improving work efficiency.

In summary, the ER-MIMU-09 stands out with its unique design, high performance, low power consumption, wide temperature compensation, and efficient communication, providing precise and reliable measurement data for oil logging and mining exploration, and helping to achieve technological innovation and performance improvement.
