High-performance, low-cost IMU improves your flight experience

As the drone industry develops rapidly, high performance and low cost have become the goals that manufacturers are competing for.

The drone's sensor is crucial to ensure the stability, accuracy and environmental adaptability of the drone. IMU is an important sensor for drones, located in the core position, which can ensure the normal operation of the device function and navigation.

We have an IMU ER-MIMU-M02 that integrates an accelerometer, gyroscope, magnetometer and barometer sensor. It has excellent performance and low cost, meeting user needs.

High Performance, Low Cost Imu Improves Your Flight Experience

Gyroscope and accelerometer provide the angular velocity and acceleration of the drone. These data can be used to calculate the attitude, speed, displacement and other information of the drone, and can also be used to maintain the stability of the drone and prevent shaking.

Magnetometers can provide a sense of direction for drones. It can provide data on the magnetic field to which the drone is subjected.

Barometers measure atmospheric pressure and provide data that can assist drone navigation and rise to the required height. Accurately estimating the ascent and descent speeds is very important for drone flight control.

【High performance, low cost】

The gyroscope has a measurement range of ±450º/s and a bias instability of 2 º/h; the accelerometer has a measurement range of 16g and a bias instability of 24μg (Allen variance); the magnetometer has a measurement range of ±2.5Gauss; the barometer has a pressure range of 450~1100mbar, which meets the needs of drones.

It can be produced in a short cycle, large batches, and on a large scale with stable quality, which is particularly suitable for users with large demand and limited budget.
