Do you Know How to Make Measurements Faster and More Accurate?

RTK measuring instruments play an important role in open-pit mining. During the measurement process, are you always worried that the measurement results are not accurate enough or that some measurement locations cannot receive signals?



ERICCO's IMU ER-MIMU-11 can perfectly solve the above problems while improving measurement efficiency, increasing measurement and layout speed by 30%!





RTK surveying instruments use GPS technology for real-time positioning and measurement. When measuring some obstructed or inconvenient locations, the signal will be blocked, resulting in inaccurate or even impossible measurements. At the same time, due to the special environment of the mine, the measurement accuracy will also be affected by the magnetic field.



Next, let's take a look at the main advantages of this IMU!

1. The cylindrical IMU with a diameter of only 30mm is seamlessly integrated into the RTK survey instrument for real-time interference-free and automatic tilt compensation.
2. Walk a few meters, initialize the internal IMU, and easily start the measurement mode!
3. Even if you move, tilt, or level the measuring rod, you don't need to go through the tedious calibration process, and you can continue measuring immediately while ensuring measurement accuracy.
4. IMU is an inertial measurement unit, which is not affected by external interference, can ignore magnetic fields, and can accurately measure in difficult sites.
5. It can measure at a large tilt angle, and in some special places (such as corners), it can also easily complete the measurement work.



RTK is widely used in mining from preliminary measurement to site acceptance, line transportation and safety monitoring. Its work efficiency affects the operating efficiency of the entire mine.

---
