Triaxial OEM MEMS Gyro: The Core Sensing "Genie" for North Finding

In the field of mine safety production, the gyroscope in north finding equipment is undoubtedly a crucial technical tool. It can output angular velocity to provide solid data support for mining operations.



ERICCO's ER-3MG-01mini 3-Axis North-Seeking MEMS Gyro is a three-axis gyroscope that is very suitable for North finding. Why is it a sensing “genie”? Because it has the following advantages:



Triaxial Oem Mems Gyro The Core Sensing Genie For North Finding

** OEM**

ER-3MG-01mini provides OEM custom service, it adopts modular design, the inner tube body is Chinese "Ding" shape, so it has high stability. Integrate our three-axis gyroscope into your module or system and get data in just a few simple steps without the need to use the 15-pin plug provided by our company. By removing the substrate shell, the size and weight of our products can also be greatly reduced.



** High precision **

This three-axis gyroscope is divided into ABC three types, bias instability value up to 0.01deg/hr, as shown in the following table:



Parameters ER-3MG-01mini A ER-3MG-01mini B ER-3MG-01 mini C
Range 50deg/s 100deg/s 200deg/s
Bias Instability(1σ 25℃) <0.01deg/hr <0.02deg/hr <0.02deg/hr
Bias stability (10s 1σ) <0.05deg/hr <0.1deg/hr <0.1deg/hr



For users who need high-precision three-axis MEMS gyro, you can choose any of the above according to the actual application scenario.



** Small size, light weight **

ER-3MG-01mini volume 40*40*42(mini version with shell) weight is 80g, /27*26*34(mini version without shell and baseboard) weight is only 40g, The compact and compact design is easy to integrate into a north finding device.



During mining, our three-axis MEMS gyroscope ER-3MG-01 is integrated into the north finding equipment, which provides timely angular velocity data and ensures accurate driving direction to help miners work efficiently.
