The GNSS integrated navigation system can make up for the shortcomings of GNSS when the signal is blocked or interrupted and the problem of low satellite refresh rate, aiming to improve the accuracy and reliability of navigation.
Our integrated navigation ER-GNSS/MINS-05 is the most cost-effective one. It has high reliability and reasonable price. It can provide continuous and high-precision position, heading, speed and attitude information.
**High-precision positioning and orientation**
The product has a highly reliable and low-cost MEMS gyroscope (measurement range is ±450°/s, bias instability <2°/h) and accelerometer (measurement range is ±16g, bias instability <25ug).
The integrated navigation information provided has a roll and pitch accuracy of up to 0.1° and post-processing of 0.03°. The heading can reach 0.1°, 0.05° after post-processing, and the speed accuracy can reach 0.03m/s.
RTK interruption for 30 seconds, the roll and pitch accuracy can be maintained at 0.03°, and the heading accuracy can be maintained at 0.06°.
**Full-band full-system**
The built-in dual-antenna positioning and directional GNSS module supports all major global satellite navigation systems and is compatible with multiple frequency points to ensure the best positioning results anywhere in the world.
Supports RTK positioning, automatically identifies RTCM, and enters RTK state.
**Strong anti-interference ability**
The built-in satellite receiver has strong anti-interference ability, can still provide accurate positioning in complex electromagnetic environments, and supports multiple communication interfaces.
**Small size and light weight**
The size is only 65×70×45.5mm, the weight is less than 240g, and the aluminum alloy shell ensures the reliability of the product.
The operating temperature range can reach -40°C to 80°C, and the low power consumption design of 5W is suitable for most working environments.
**Multi-field application**
It is suitable for large and medium-sized unmanned aerial vehicles, flight recorders, intelligent unmanned vehicles and roadbed positioning and orientation, etc.
