Precise Application of High-Performance Dynamic FOG North Seeker in Mining and Oil Exploration

The orientation accuracy of drilling equipment directly affects the efficiency and safety of logging drilling, tunnel excavation, and ore body positioning. During underground drilling operations, the vibration and attitude changes of the drilling rig are frequent, and traditional mechanical gyroscopes or magnetic compasses are difficult to work stably.

Precise Application Of High Performance Dynamic Fog North Seeker In Mining And Oil Exploration

ER-FNS-01D high-performance dynamic FOG north seeker can achieve real-time accurate north seeking and attitude following in a vibrating environment. The north seeking accuracy can reach 0.5°, and the attitude measurement accuracy can reach 0.03° (1σ). Dynamic north-seeking technology can provide the true north direction of the carrier in real time. The working latitude of 65°N-65°S covers major mining areas and oil and gas fields around the world, ensuring that the drilling rig can still accurately control the drilling direction even when tilted or vibrating.

The compact size of 100×100×75mm and the lightweight design of 1kg make it easy to integrate into drilling equipment. Its core technical advantages are precisely targeted at complex working conditions:

Fast and precise dual modes: Supports 30-second fast alignment (azimuth accuracy 1°) and 90-second precise alignment (azimuth accuracy 0.5°), significantly shortening the equipment startup time. It can quickly establish the north reference after the drilling rig is in place. At the same time, its 20-minute accuracy retention capability allows the drilling rig to quickly resume operations after a short stop, reducing the time loss caused by repeated alignment.

Full environment adaptability: 5℃-55℃ full temperature range compensation technology adapts to the temperature difference between the deep mine and the field; there is humidity, dust and potential electromagnetic and metal interference in the mine, and the ER-FNS-01D is not affected by the magnetic field, which completely avoids the influence of the electromagnetic environment on the measurement results.

Strong vibration adaptability: The built-in shock absorber design can withstand 20Hz-2000Hz, 6.06g vibration environment, solving the problem of accuracy drift caused by vibration in dynamic operations of traditional north-seeking equipment.
