The north seeker can provide azimuth and attitude information (pitch, roll) by itself, and can be integrated into various equipment systems that require directional alignment and attitude measurement.
There are many application fields, such as: determining drilling direction, mineral exploration equipment, boring machine, tunnel construction, static initial alignment, direction control and tracking of radar, antenna, vehicle, etc.
ERICCO's MEMS north seeker ER-MNS-05Mini has the characteristics of small size, high precision, low power consumption and high stability.
This north seeker has the following main advantages:
**Small size**
The size of ER-MNS-05 Mini is 40*40*42 (mini version with shell)/27*26*34 (mini version without shell and baseboard), and the weight is <80g (mini version with shell)/ 40g (mini version without shell and baseboard).
**High-precision north-seeking and orientation**
The north-seeking accuracy of this MEMS north-seeker can reach 0.25°secψ(1σ)! Provide more accurate azimuth, pitch, and roll angle information. The inclination measurement range is -85°~85°. And it is not affected by magnetic fields and can be used in magnetic mining areas.
There are three models with different accuracy, with north-seeking accuracy of 0.25°secψ(1σ), 0.5°secψ(1σ), and 1°secψ(1σ), respectively. Users can choose according to their needs.
**OEM customization**
Connect the product to your system and acquire data in just a few simple steps, without using the 15-pin plug provided by our company. By removing the baseplate casing, the size and weight of our products can also be significantly reduced.
**Resistant to harsh environments**
The operating temperature range is 5°C~+55°C and only requires 2W power.
The inner platform body has a unique design, giving the product extremely high stability and reliability, and it can work stably even under harsh conditions of high impact and strong vibration.
To sum up, north seekers are crucial for application scenarios that require precise orientation and attitude measurement.
