Nine-axis IMU: Empowering drones and opening a new era of intelligent flight

With the advancement of technology, the field of drones is undergoing unprecedented changes, and IMU is undoubtedly the key force in this change. As a professional, you must be well aware of the significance of cutting-edge technology in reshaping the industry. Today, we will take you to explore the unlimited potential of IMU in the drone industry.

Take a nine-axis IMU ER-MIMU-07 as an example. It has three-axis gyroscope, three-axis accelerometer and three-axis magnetometer. It can accurately capture every subtle movement and attitude change of the drone in three-dimensional space and provide accurate data in real time. The flight control system can quickly calculate the current attitude, speed, displacement and other information of the drone based on the data transmitted by the IMU.

Nine Axis Imu Empowering Drones And Opening A New Era Of Intelligent Flight

High-precision sensor: details determine success

The built-in gyroscope has a measurement range of 400º/s, bias instability <0.3 º/h, and angular random walk <0.125°/√h. The accelerometer has a measurement range of 30g, bias stability <50ug, and bias repeatability of 100ug.

The data provided by the IMU to the flight control system can monitor the pitch, roll, and yaw attitude of the drone in real time. Once the drone is disturbed by the outside world, the IMU can quickly detect it and transmit the data to the flight control system for timely adjustment and correction, so that the drone can restore a stable flight attitude.

Small and lightweight: flexible adaptation and installation

With the development trend of drones pursuing portability and efficiency, small and lightweight design has become a highlight. This IMU is only 38.6x 44.8 x25.5mm in size and weighs ≤70g, which can be easily installed in a small fuselage space.

This compact design is not only easy to install, but also provides the possibility for optimizing the structural layout of the drone, allowing engineers to integrate more functional modules in a limited space.

Better performance, lower price

This IMU simplifies and reduces design costs while maintaining high performance. Its performance is better than STIM300, but the price is lower, helping drones reduce costs.

If you are in the drone industry, whether you are engaged in whole machine manufacturing, system integration, or application development in a specific field, IMU will inject strong impetus into your project. We have a professional technical team that can not only provide you with top-quality IMU products, but also customize solutions according to your unique needs, helping you stand out in the fiercely competitive market.
