HDD Technology Breakthrough! North seeker Helps with Orientation in Trenchless Construction

As the core technology of trenchless pipeline laying, HDD technology places extremely high demands on the direction control of the drill bit. The precise control of the drilling trajectory depends on high-performance directional measurement equipment. With its unique technical advantages, the ER-MNS-09 north seeker has become a key equipment for improving construction efficiency and accuracy in HDD operations.

Hdd Technology Breakthrough! North Seeker Helps With Orientation In Trenchless Construction

Core challenges and directional requirements of HDD construction

HDD construction requires the completion of pilot hole drilling, hole expansion, and pipeline pullback processes underground. Directional equipment needs to meet the requirements of narrow space adaptation, high-precision orientation, resistance to complex environmental interference and impact vibration, and adaptation to extreme working conditions.

ER-MNS-09’s technical advantages and HDD compatibility

High-precision measurement to ensure trajectory control

The azimuth accuracy can reach 0.25°, and the attitude accuracy is ≤0.2°. With a data update rate of 100Hz, it supports stable operation in the inclination range of -85~85°. The operator can adjust the drill bit trajectory in time based on the measurement data to meet the strict restrictions on trajectory deviation in HDD construction;

Ultimately compact design, embedded in the core space of the probe tube

The HDD guided probe pipe needs to be embedded in the front end of the drill pipe, and the size and weight of the equipment are limited. The ER-MNS-09 north seeker has a diameter of only 30mm, a length of 120mm, and a weight of ≤150g. It can be seamlessly integrated into the probe pipe or guide head at the front of the drilling equipment, and is suitable for mainstream drilling equipment.

Autonomous north finding and anti-magnetic interference

Adopting a high-precision MEMS gyroscope that can self-find north, the initial alignment is completed in 5 minutes, completely free from dependence on the geomagnetic field, and can stably output the true north azimuth, pitch angle and roll angle information in strong interference environments such as underground mines, metal pipelines or strong electromagnetic environments.

All-solid-state design: no mechanical rotating parts, excellent anti-impact and vibration ability, meeting the reliability requirements under severe vibration conditions during drilling.

Wide temperature adaptability to cope with extreme working conditions

Full temperature calibration compensation: The normal temperature version supports an operating temperature of 5~+55°C, and the high temperature version supports 5~125°C. It can withstand strong vibration and shock environments to ensure long-term reliability in deep wells, mud environments or high shock conditions.
