Do You Want Your Drone to Fly More Safely and Stably in the air?

In order to achieve stable flight, precise navigation and perform various tasks, drones usually integrate multiple sensors. As one of the core components of drones, IMU plays an irreplaceable role.

ERICCO's ER-MIMU-M02 is a 10-axis IMU, which is a 10-axis IMU with the addition of a 3-axis magnetometer and barometer, making it perfect for drones.

The IMU measures the acceleration and angular velocity of the drone, providing critical flight control data for the drone.

The magnetometer measures the magnetic field strength in three dimensions, helping to determine the heading, roll, and pitch of the drone.

The barometer accurately measures atmospheric pressure, providing a clear view of the drone’s altitude information.

Do You Want Your Drone To Fly More Safely And Stably In The Air

【Ultra-thin thickness】

This IMU is only 14mm thick, 47×44×14mm in volume, 50g in weight, and has low power consumption.

【Stable performance】

The dynamic measurement range of the built-in gyroscope is ±450º/s, the bias instability is 2 º/h, and the angular random walk is 0.08º/√h. The dynamic measurement range of the accelerometer is ±16g, the bias instability is 24μg (Allen variance), and the angular random walk is 0.02m/s√h.

【Low cost, mass production】

This IMU has a short production cycle and can be mass-produced on a large scale, which is particularly suitable for users with large demand and limited budget.

【Wide application】

With the advancement of technology, the market size of IMU continues to grow. This IMU can also be used in application fields such as autonomous driving and robotics.
