Breaking through tradition! New MEMS north finder installed near the drill bit, with higher precision!

With the continuous exploitation of oil and coal mines, the difficulty of exploration and development work has increased. The traditional inclinometer is far away from the drill bit, and the measured information has errors. How to ensure accurate drilling direction in a complex and ever-changing underground environment? The north finder is indispensable!

Currently, most MEMS north finders need to be installed on the guide rail of the drilling rig or on a stable plane.

ERICCO's north finder ER-MNS-09, with its new cylindrical shape, can be directly installed in the drilling rig probe, providing information such as the attitude and azimuth of the drill tool, greatly improving work efficiency and safety.

Breaking Through Tradition! New Mems North Finder Installed Near The Drill Bit, With Higher Precision!

Near-bit installation

The cylindrical shape, with a length of 120mm and a diameter of only 30mm, can be placed directly near the drill bit or in the drilling rig probe. This allows drilling engineers to obtain accurate wellbore trajectory information and more accurately understand the position and attitude of the drill bit.

High North-seeking Accuracy

The current MEMS north-seeking accuracy is only 1°secψ(1σ) or 0.5°secψ(1σ). However, this device can achieve a north-seeking accuracy of 0.25°secψ(1σ). It also has self-alignment and attitude tracking functions, which do not require manual alignment. It is essential for drilling operations that require rapid deployment and high-precision positioning.

Shock and vibration resistance, stable operation

Due to the strong shock and vibration during drilling, it can resist high shock and vibration, ensuring stable operation in harsh environments. The low-power design ensures stable performance output even in continuous operation.

If you are also looking for a tool that can improve work efficiency, then you might as well try our MEMS north finder!
