IMU/VRU/AHRS

ER-AHRS-10 (6 deg/hr)
1.Industrial-grade inertial sensors
2.3 ° dynamic attitude accuracy
3.Stable heading output
4.Factory calibrated in full temperaturerange

Share to:

Introduction

ER-AHRS-10 IMU/VRU/AHRS

Introduction
The ER-AHRS-10 inertial sensing system integrates industrial-grade MEMS gyroscope and accelerometer, which can output 3D angular velocity, acceleration, magnetic field information, and fused 3D azimuth angles.When connected to a satellite navigation (GNSS) signal, fused position and velocity information can be output. ER-AHRS-10 includes ER-AHRS-10U Inertial Measurement Unit (IMU), ER-AHRS-10V Vertical Reference System (VRU), ER-AHRS-10A Attitude Reference System (AHRS)

The ER-AHRS-10 is embedded with multi-sensor fusion algorithm, which has been calibrated at the factory in all temperature ranges to ensure the excellent performance of the system in harsh environments. The compact design of the ER-AHRS-10 makes it easy for customers to integrate applications and shorten the development cycle.

The ER-AHRS-10 has a dynamic attitude detection accuracy of 0.3° and provides a stable, low-drift relative heading output and a drift-free absolute heading output. It can meet the attitude, direction stability control, positioning and navigation needs of various carriers in complex and harsh application environments.

Features
Stable heading output
3 ° dynamic attitude accuracy
Industrial-grade inertial sensors
Gyro bias instability: 6 °/h
Accelerometer bias instability: 0.05mg

Application
Robots, unmanned vehicles
Construction machinery, intelligent agricultural machinery
Satcom on the move/Communication in Moving

Product model information

Items	ER-AHRS-10U	ER-AHRS-10V	ER-AHRS-10A
Angular velocity, acceleration	√	√	√
Attitude angle		√	√
Relative heading angle		√	√
Absolute heading angle			√

Specifications:

Attitude orientation performance

Attitude angle		0.3 °	1σ RMS
Heading angle	Relative heading angle* Absolute heading angle**	0.8 °	1σ RMS
		1 °	1σ RMS
Sensor parameters
Gyroscope		Accelerometer	Magnetic sensors
Range ±500 °/s		±16g	±8 Gauss
Non-linearity ±0.05%FS		±0.5%FS	±0.2%FS
Bias instability*** 6 °/h		0.05mg	-
Noise density 0.015 °/s/√ Hz		100μg/√ Hz	0.4mG (RMS)
Bandwidth 116Hz		116Hz	-
System parameters
Input voltage 3.3- 16VDC		Size	37.7249.5mm
Power consumption 250mW		Weight	15.5g
Operating temperature -40~85℃		Hardware interface	SPI UART
		Output frequency	200Hz
Note: The above parameters are typical values * Provides a relative heading angle without reference，Regular motion drift<0.8 °/min，Static drift<0.8 °/hr。 In a homogeneous magnetic field environment * Allan variance，1σ @25℃
